Hydrogen fuel purity, the full ISO 14687 panel in under four minutes

Hydrogen's value is defined by what has been removed from it. ISO 14687:2025, the international specification for hydrogen fuel quality, sets a minimum purity of 99.97% by mole fraction. The remaining 0.03% is governed by contaminant limits measured in micromoles per mole, and for total sulphur, in parts per billion. Europe's EN 17124:2026 and North America's SAE J2719 enforce parallel regimes, and all three increasingly require ongoing monitoring rather than a single batch certificate.

The penalties are steep. A single contaminated load can shut a refuelling station, void a fuel-cell stack warranty and trigger a liability dispute that propagates back through the supply chain. The AirBreather platform verifies the full specification continuously, measuring more than 50 targeted impurities in a single cycle of under four minutes, across up to 40 sample points.

Request a hydrogen purity assessment

The ISO 14687 panel, and how AirBreather measures it

No single analyser can resolve this panel in a matrix that is otherwise near-pure hydrogen. AirBreather combines four analytical engines on one platform: FTIR for broad-spectrum molecular detection, gas chromatography for diatomics and noble gases, GC with photo-ionisation detection for sub-ppb sulphur, and a dedicated oxygen sensor. Detection limits are set well below the ISO 14687 thresholds.

Impurity	ISO 14687 limit	AirBreather technique
Water (H₂O)	5 µmol/mol	FT-2 FTIR
Total hydrocarbons (as C₁)	2 µmol/mol	FT-2 FTIR
Carbon monoxide (CO)	0.2 µmol/mol	FT-2 FTIR
Formaldehyde (HCHO)	0.2 µmol/mol (0.01 under SAE J2719)	FT-2 FTIR
Formic acid (HCOOH)	0.2 µmol/mol	FT-2 FTIR
Ammonia (NH₃)	0.1 µmol/mol	FT-2 FTIR
Carbon dioxide (CO₂)	2 µmol/mol	FT-2 FTIR
Halogenated compounds	0.05 µmol/mol	FT-2 FTIR
Nitrogen, argon, helium	100 to 300 µmol/mol	MicroGC (TCD)
Total sulphur compounds	0.004 µmol/mol (4 ppb)	GC-PID, sub-ppb
Oxygen (O₂)	5 µmol/mol	UV-fluorescent oxygen sensor
Particulates	1 mg/kg	Gravimetric filtration

Why the limits are this tight

The constraints come from PEM fuel-cell chemistry. Carbon monoxide degrades the catalyst below 0.2 µmol/mol; hydrogen sulphide poisons it at low ppb; ammonia attacks the membrane directly. Halogenated compounds and sulphur dioxide cause damage that flushing will not reverse, where the only remedy is component replacement. Measuring well below each limit is what gives a producer or station operator room to act before a pass becomes a failure.

From spot sampling to continuous, traceable analysis

Sending a bottled sample to an external laboratory tells you about one batch, not what happens between batches. EN 17124:2026 names ongoing monitoring directly in its quality-assurance framework. Continuous on-site analysis across the full panel closes that gap, and it produces the documentation buyers, regulators and insurers now ask for: certificates of analysis, validation logs and electronic records aligned to 21 CFR Part 11. The AirBreather platform issues a secure Certificate of Analysis, runs continuous multi-point analysis, and supports remote operation and diagnostics.

Frequently asked questions

What purity does ISO 14687 require for hydrogen fuel?
A minimum of 99.97% hydrogen by mole fraction, with the balance governed by per-contaminant limits in micromoles per mole, and total sulphur limited to 0.004 µmol/mol (4 ppb).

Can one analyser measure the whole ISO 14687 panel?
No single technique covers it. AirBreather combines FTIR, gas chromatography with thermal conductivity detection, GC-PID for sub-ppb sulphur, and a dedicated oxygen sensor on one platform, measuring more than 50 impurities below the ISO 14687 limits.

How fast is a full hydrogen purity analysis?
AirBreather completes a full cycle in under four minutes across up to 40 sample points, enabling continuous monitoring rather than periodic bottle sampling.
